Click Jaws

Yes, "Click Jaws". They just click in or click out while maintaining a .0002" accuracy! Is there anything faster than that? These soft jaws are fully customizable, so use them for different jobs and save time on change-overs.
The Video at right shows just how fast you can change out your soft jaws. Once you install "Master Jaws" on your standard Kurt Vice, you are ready to rapidly change out your "Click Jaws". We show you this product first, because it illustrates how we have reduced the problem down to it's simplest form.
Eddy Engbar has applied this model to all of our products. FAST AND SIMPLE CHANGE-OVERS. In this package you will receive 2 of the aluminum Click Jaws

Price $49 (1 set of Click Jaws)

Watch how we change a set of soft jaws in less than 30 seconds!

Master Jaws (for Kurt Vice Standard)

Click Jaws

The "Master Jaws" (1 set) are mounted to your Kurt Vise, and are then ready to receive the "Click Jaws" (sold separately). Master jaws are easy to install on your standard Kurt Vise, and will replace the jaws that came with the vise. Only one Master Jaw set is needed per vise. If you notice, the master jaws have a center pin and two spring loaded pins that self center the soft jaws when coupled. These three points of connection allow for the precise accuracy customers expect from TED Tooling.
The picture at right, shows one click jaw and one master jaw. In this package you will receive 2 of the steel Master Jaws

Price $149

Base Pallet

Ted Tooling Base Pallet

The base pallet is a receiver for a multiple pallet system. This standard base receives the Plain Pallet, Grid Pallet, or Slotted Pallet for rapid, less than 2 minute change overs, while maintaining a .0002" accuracy. Simply remove the single front screw, slide the pallet into position, and replace the single screw. The loaded pallet is now held in position at four different points, making this pallet system both fast, accurate and secure. High rigidity for heavy duty machining, and has a Rockwell hardness of 62. Dimensions are 10" x 14" x 1.25"

Price $1,499

Change out any pallet with ONE SCREW !

Plain Pallet

Ted Tooling Base Pallet

The Plain Pallet is machinable, 7075 grade aluminum, customizable to accept any clamping fixture or tool. When you customize the mounting points, you can expect fast, under 2 minute change overs, while maintaining a .0002" accuracy. High rigidity for heavy duty machining. Dimensions are 12" x 15" x 1.5" (Shown here, the plain pallet is quick connected to the base pallet - sold separately)

Price $599

Grid Pallet

Ted Tooling Base Pallet

The Grid Pallet is universal and ready to accept any clamping fixture or tool. This grid has 1/2" x 13 threads per inch mounting points, spaced 2" apart. You can expect fast, less than 2 minute change overs, while maintaining a .0002" accuracy. High rigidity for heavy duty machining and made from 7075 grade aluminum. Dimensions are 12" x 15" x 1.5"

Price $1,199

Your "Work Zero" (program zero) is preserved between changeovers !

Serrated Pallet

Serrated Pallet

The "Serrated Pallet" is a slotted and serrated pallet that accepts various tooling or work-holding elements. The serrations are like small teeth that align and hold a tool for fast, secure locking to the pallet. You can expect fast, under 2 minute change overs, while maintaining a .0002" accuracy. High rigidity for heavy duty machining and made from 7075 grade aluminum. Dimensions are 12" x 15" x 1.5" (base pallet sold separately)

Price $1,499

Multi Vise

Ted Tooling - Multi Vise

The Multi Vise is able to hold many items at one time and includes the Serrated Pallet and minimum set-up. This option must be customized to your needs.

Please Call 702-577-2353 for pricing

Mounting Plate

Ted Tooling - Multi Vise

The "Mounting Plate" is the first item needed in the Ted Tooling Pallet System. All other Pallets mount to this. Shown here, a base pallet (sold separately) bolted to the mounting plate

Please Call 702-577-2353 for pricing


Load extra pallets between runs. Quick change out, hit start and you are up running.



Engbar Turret Animation
Work holding tool features:
  • Precision and Repeatability
  • Accurate to .0002"
  • Ridged and Heavy Duty
  • Highest Quality Materials
  • Customizable and Machinable
  • Lifetime Warranty
Our principal machinist / engineer Eddy Engibarian, has many years of experience developing tooling and work-holding systems for machine shops around the world. Eddy is a specialist in mass production and fast change-overs and is well known in the industry. Quality and perfection is our rule. Thank you for your interest in TED Tooling
Eddy Engbar


When you call, you'll speak with a live, competent expert in work holding and quick change tooling.
